Max. Forming Frame Area:
570 × 440 mm

Sheet Thickness (Min–Max):
0.20 mm – 0.80 mm

Maximum Draw Depth:
Up to 150 mm

Approximate Weight:
700 kg

Raw Materials Supported:
HIPS, PET, PVC
(PP with optional bottom heater box)

Production Speed:
8–10 cycles per minute

Sheet Width (Max–Min):
600 – 470 mm

Power Supply:
18.0 kW

Compressed Air Requirement:
7 kg/cm²

Forming Configuration:
Inline forming with punching and cutting
Bottom heater box (sandwich heating) – optional

Machine Controls:
Servo motor & drive-based control with PLC
